Oligo Synthesis

Oligo Synthesis : CEPs

Prices quoted are for single packs only. For multiples of the same product please request a quote. Some of Glen's products are hazardous and may be subject to additional shipping charges. Full product information is available on Glen Research's website.

BHQ-1-dT

BHQ-1-dT

Glen Research

Catalogue No.DescriptionPack SizePriceQty
10-5941-02BHQ-1-dT 0.25g £1,214.00 Quantity Add to Order
10-5941-90BHQ-1-dT 100µmoles £673.00 Quantity Add to Order
10-5941-95BHQ-1-dT 50µmoles £336.00 Quantity Add to Order
40-4450-20 Diluent optional Anhydrous Acetonitrile/Dichloromethane20ml £0.00 Quantity Add to Order

Description

BHQ-1-dT


Catalog Number: 10-5941-xx

Description: BHQ-1-dT

5'-Dimethoxytrityloxy-5-[(N-4''-carboxyethyl-4''-(N-ethyl)-4'-(2-Nitro-4-toluyldiazo)-
2'-methoxy-4'-methyl-azobenzene)-aminohexyl-3-acrylimido]-2'-deoxyUridine-
3'-[(2-cyanoethyl)-(N,N-diisopropyl)]-phosphoramidite
Formula: C74H89N12O14P M.W.: 1401.56 F.W.: 960.93


Diluent: Anhydrous Acetonitrile/Dichloromethane 1:3 (v/v) - code :40-4450-20

Please request with your order if required.

Coupling: 10 minute coupling recommended
Deprotection: No changes needed from standard method recommended by synthesizer manufacturer.
Storage: Freezer storage, -10 to -30°C, dry
Stability in Solution: 2-3 days
Please Note: 'Black Hole Quencher', 'BHQ-0', 'BHQ-1', 'BHQ-2' and 'BHQ-3' are trademarks of Biosearch Technologies, Inc., Novato, CA. The BHQ dye technology is the subject of pending patents and is licensed and sold under agreement with Biosearch Technologies, Inc.. Products incorporating the BHQ dye moiety are sold exclusively for R&D use by the end-user. They may not be used for clinical or diagnostic purposes and they may not be re-sold, distributed or re-packaged.

Black Hole Quencher Dyes

With the growing popularity of red and near-infrared dyes, we are offering the Black Hole QuencherTM dyes (BHQs), whose physical properties are detailed in Table 1. BHQ dyes are robust dark quenchers that very nicely complement our existing product line. They are compatible with ammonium hydroxide deprotection, exhibit excellent coupling efficiencies, have large extinction coefficients and are completely non-fluorescent. Their absorbances are well-tuned to quench a variety of popular fluorophores – even those far into the red, such as Cy3 and Cy5. The dark quencher most typically used in a Molecular Beacon is Dabcyl. Because the quenching does not involve FRET, there is little, if any, dependence upon donor-acceptor spectral overlap. In a comprehensive paper by Marras, Kramer and Tyagi,1 the ability of BHQ-1 and BHQ-2 to quench 22 different fluorophores was evaluated. For shorter wavelength fluorophores such as fluorescein, the quenching efficiency was roughly the same as Dabcyl (91% – 93%). However, for dyes emitting in the far red, such as Cy5, the BHQ dyes were far superior – quenching the Cy5 with 96% efficiency, compared to 84% with Dabcyl. This may reflect the BHQ’s ability to form stable, non-fluorescent complexes which can be a plus even in FRET probes. Indeed, recent work suggests that these non-fluorescent complexes will form even in the absence of a hairpin stem structure used by Molecular Beacons.2

If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

Protocols

Material Safety Data Sheet

Glen Report 21.2: Deprotection - Volume 3 - Dye-Containing Oligonucleotides

If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

References

(1) S.A.E. Marras, F.R. Kramer, and S. Tyagi, Nucleic Acids Res., 2002, 30, E122.

(2) M.K. Johansson, H. Fidder, D. Dick, and R.M. Cook, J Am Chem Soc, 2002, 124, 6950-6956.

"Black Hole Quencher", "BHQ-0", "BHQ-1", "BHQ-2" and "BHQ-3" are trademarks of Biosearch Technologies, Inc., Novato, CA. The BHQ dye technology is the subject of pending patents and is licensed and sold under agreement with Biosearch Technologies, Inc.. Products incorporating the BHQ dye moiety are sold exclusively for R&D use by the end-user. They may not be used for clinical or diagnostic purposes and they may not be re-sold, distributed or re-packaged.

If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

Notes

Frequently Asked Technical Question

QUESTION: What are the physical properties of the various black hole quenchers?

RESPONSE:

Quencher lmax (nm) E260 (L/mol.cm) Emax (L/mol.cm)
BHQ-0 493 7,700 34,000
BHQ-1 534 8,000 34,000
BHQ-2 579 8,000 38,000
BHQ-3 672 13,000 42,700

REFERENCE(S):
Glen Report 17.1







































If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

Applications & Benefits

DILUTION/COUPLING DATA

The table below shows pack size data and, for solutions, dilutions and approximate couplings based on normal priming procedures. Please link for more detailed usage information with the various synthesizers.

ABI 392/394
Cat.No. Pack
Size
Grams/
Pack
0.1M Dil.
(mL)
LV40 LV200 40nm 0.2µm 1µm 10µm
Approximate Number of Additions
10-5941-02 0.25grams .25grams 1.78 46 27.6 17.25 12.55 9.2 2.3
10-5941-90 100µmoles .14grams 1 20 12 7.5 5.45 4 1
10-5941-95 50µmoles .07grams .5 3.33 2 1.25 .91 .67 .17
Expedite
Cat.No. Pack
Size
Grams/
Pack
Dilution
(mL)
Molarity 50nm 0.2µm 1µm 15µm
Approximate Number of Additions
10-5941-02 0.25grams .25grams 2.66 .07 46.8 29.25 21.27 2.93
10-5941-90 100µmoles .14grams 1.5 .07 23.6 14.75 10.73 1.48
10-5941-95 50µmoles .07grams .75 .07 8.6 5.38 3.91 .54
Beckman
Cat.No. Pack
Size
Grams/
Pack
Dilution
(mL)
Molarity 30nm 200nm 1000nm

Approximate Number of Additions
10-5941-02 0.25grams .25grams 2.66 .07 48.4 30.25 22

10-5941-90 100µmoles .14grams 1.5 .07 25.2 15.75 11.45

10-5941-95 50µmoles .07grams .75 .07 10.2 6.38 4.64
