Cambio - Excellence in Molecular Biology

Oligo Synthesis

Oligo Synthesis : CEPs

Prices quoted are for single packs only. For multiples of the same product please request a quote. Some of Glen's products are hazardous and may be subject to additional shipping charges. Full product information is available on Glen Research's website.

Thymidine Glycol CE Phosphoramidite

Thymidine Glycol CE Phosphoramidite

Glen Research

Catalogue No.DescriptionPack SizePriceQty
10-1096-02Thymidine Glycol CE Phosphoramidite 0.25g £1,032.00 Quantity Add to Order
10-1096-90Thymidine Glycol CE Phosphoramidite 100µmoles £436.00 Quantity Add to Order
10-1096-95Thymidine Glycol CE Phosphoramidite 50µmoles £227.00 Quantity Add to Order

Description

Thymidine Glycol CE Phosphoramidite

Structure

Catalog Number: 10-1096-xx

Description: Thymidine Glycol CE Phosphoramidite

5'-Dimethoxytrityl-2'-deoxy-(5R,6S)-5,6-bis(t-butyldimethylsilyloxy)-
5,6-dihydroThymidine,3'-[(2-cyanoethyl)-(N,N-diisopropyl)]-
phosphoramidite
Formula: C52H79N4O10PSi2 M.W.: 1007.36 F.W.: 338.21

Diluent: Anhydrous Acetonitrile
Coupling: 3 minute coupling time is recommended. Monomers that allow for UltraMILD deprotection must be used. (Catalog Numbers: dA: 10-1601-xx, dC: 10-1015-xx, dG: 10-1621-xx, dT: 10-1030-xx.). To avoid any exchange of the iPr-Pac group on the dG with acetyl, use the UltraMild Cap Mix A (40-4210-xx/ 40-4212-xx).
Deprotection: Cleave and deprotect the oligonucleotide in 30% Ammonium Hydroxide for 2 hours at Room Temperature. Dry down and dissolve the residue in 0.5 mL of TEA.3HF and keep at 40° C overnight to remove the TBDMS protecting groups. Add an equal volume of dH2O and desalt on a Glen Gel-Pak™ column or equivalent.
Storage: Freezer storage, -10 to -30°C, dry
Stability in Solution: 2-3 days

8-Amino-G is formed along with 8-oxo-G as the major mutagenic lesions formed in DNA damage caused by 2-nitropropane. 2-Nitropropane is an industrial solvent and a component of paints, dyes and varnishes, and is also present in cigarette smoke. Thymine glycol (5,6-dihydroxy-5,6-dihydrothymine) is formed when thymine is subjected to oxidative stress, including ionizing radiation. Oxidation of the 5,6 double bond of Thymidine generates two chiral centers at C5 and C6. The cis-5R,6S form is generated as the predominant product along with the other diastereomer, the cis-5S,6R form. The presence of thymidine glycol in DNA has significant biological consequences and many organisms possess specific repair enzymes for the excision of this lesion. 2-Aminoimidazolone (Iz) and its hydrolysis product imidazolone (Z) are major oxidation products of G. Access to these two potential lesions is not possible during oligonucleotide synthesis because they are so base-labile. A suitable precursor, 8-methoxy-dG (8-OMe-dG), to dIz has now been described. The conversion of 8-OMe-dG to dIz takes place by irradiation of the oligonucleotide (1 mM) in 50 mM sodium cacodylate buffer, pH 7, in the presence of riboflavin (50 µM) for 2 minutes on a transilluminator (366 nm), under aerobic conditions at 4°C. Surprisingly for a photochemical reaction, the conversion is virtually quantitative.


Hydrolysis of nucleoside residues in DNA occurs to generate abasic sites. Most commonly, dA sites are hydrolyzed causing depurination and leading to abasic residues. For researchers trying to determine if their source of depurination in chemical synthesis of DNA is reagent, fluidics or protocol-based, we offer a depurination-resistant dA monomer. A new chemical method allows the generation of abasic sites in double and single stranded oligonucleotides using very mild specific conditions and with very low probability of side reactions. The original Abasic Phosphoramidite (10-1924) has been discontinued since it exhibits low coupling efficiency and the post-synthesis chemistry is fairly challenging. Abasic II Phosphoramidite1 is the replacement for the preparation of a true abasic site. This product has the advantage of simplicity in that the silyl group is removed post-synthesis using aqueous acetic acid. dSpacer has also been used successfully as a mimic of the highly base-labile abasic site.

If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

Protocols

Material Safety Data Sheet

Glen Report 16.1: Minor Base and Related Novel Phosphoramidites

If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

Notes

Oligonucleotides synthesised using Thymidine Glycol and UltraMILD monomers can be cleaved using either concentrated ammonium hydroxide or 50mM potassium carbonate in anhydrous methanol.  Complete cleavage and deprotection can be accomplished at room temperature in 2-4 hours without damaging Thymidine Glycol base.  The best method to remove teh TBDMS groups was achieved using TEA.3HF at 40°C overnight.

If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

Applications & Benefits

DILUTION/COUPLING DATA

The table below shows pack size data and, for solutions, dilutions and approximate couplings based on normal priming procedures. Please link for more detailed usage information with the various synthesizers.

ABI 392/394
Cat.No. Pack
Size
Grams/
Pack
0.1M Dil.
(mL)
LV40 LV200 40nm 0.2µm 1µm 10µm
Approximate Number of Additions
10-1096-02 0.25grams .25grams 2.48 69.33 41.6 26 18.91 13.87 3.47
10-1096-90 100µmoles .101grams 1 20 12 7.5 5.45 4 1
10-1096-95 50µmoles .05grams .5 3.33 2 1.25 .91 .67 .17
Expedite
Cat.No. Pack
Size
Grams/
Pack
Dilution
(mL)
Molarity 50nm 0.2µm 1µm 15µm
Approximate Number of Additions
10-1096-02 0.25grams .25grams 3.7 .07 67.6 42.25 30.73 4.23
10-1096-90 100µmoles .101grams 1.5 .07 23.6 14.75 10.73 1.48
10-1096-95 50µmoles .05grams .75 .07 8.6 5.38 3.91 .54
Beckman
Cat.No. Pack
Size
Grams/
Pack
Dilution
(mL)
Molarity 30nm 200nm 1000nm
Approximate Number of Additions
10-1096-02 0.25grams .25grams 3.7 .07 69.2 43.25 31.45
10-1096-90 100µmoles .101grams 1.5 .07 25.2 15.75 11.45
10-1096-95 50µmoles .05grams .75 .07 10.2 6.38 4.64
