Prices quoted are for single packs only. For multiples of the same product please request a quote. Some of Glen's products are hazardous and may be subject to additional shipping charges. Full product information is available on Glen Research's website.

2-Amino-dA-CE Phosphoramidite

2-Amino-dA-CE Phosphoramidite

Glen Research

Catalogue No.DescriptionPack SizePriceQty
10-1085-022-Amino-dA-CE Phosphoramidite 0.25g £250.00 Quantity Add to Order
10-1085-902-Amino-dA-CE Phosphoramidite 100µmoles £118.00 Quantity Add to Order
10-1085-952-Amino-dA-CE Phosphoramidite 50µmoles £68.00 Quantity Add to Order

Description

2-Amino-dA-CE Phosphoramidite

Structure

Catalog Number: 10-1085-xx

Description: 2-Amino-dA-CE Phosphoramidite

5'-Dimethoxytrityl-N2,N6-bis(diisobutylaminomethylidene)-2,6-diamino-
2'-deoxypurine riboside-3'-[(2-cyanoethyl)-(N,N-diisopropyl)]-phosphoramidite
Formula: C58H83N10O6P M.W.: 1047.33 F.W.: 328.22

Diluent: Anhydrous Acetonitrile
Coupling: 15 minute coupling recommended.SEE TECHNICAL BULLETIN
Deprotection: See Technical Bulletin for details (www.glenresearch.com/Technical/TB_2-Amino-dA.pdf). Technical Bulletin
Storage: Refrigerated storage, maximum of 2-8°C, dry
Stability in Solution: 2-3 days

bases affecting duplex stability

C-5 methyl pyrimidine nucleosides are known to stabilize duplexes relative to the non-methylated bases. Therefore, enhanced binding can be achieved using 5-methyl-dC in place of dC, duplex melting temperature being increased by 1.3°. Improved stacking in this case is believed to be brought about by elimination of water molecules from the duplex. 2,6-Diaminopurine 2'-deoxyriboside (2-amino-dA) forms an additional hydrogen bond with Thymidine, thereby leading to duplex stabilization with a melting temperature increase of 3°. Our 2-amino-dA monomer exhibits fast and effective deprotection in ammonium hydroxide and it is stabilized to depurination during synthesis. Sequences with high GC content may contain mismatches and still hybridize because of the high stability of the G-C base pair. The N4-ethyl analogue of dC (N4-Et-dC) hybridizes specifically to natural dG but the stability of the base pair is reduced to about the level of an AT base pair.

AP-dC (G-clamp) enhances oligo hybridization since the AP-C....G base pair contains 4 hydrogen bonds, which makes the interaction much stronger than the regular C....G base pair with its 3 hydrogen bonds.

If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

Protocols

MSDS

Glen Report 11.1

Glen Report 23.2

If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

Notes

 2-Amino-dA-CE Phosphoramidite

5'-Dimethoxytrityl-N2,N6-bis(diisobutylaminomethylidene)-2,6-diamino-
2'-deoxypurine riboside-3'-[(2-cyanoethyl)-(N,N-diisopropyl)]-phosphoramidite
Formula: C58H83N10O6P M.W.: 1047.33 F.W.: 328.22

Diluent: Anhydrous Acetonitrile
Coupling: 15 minute coupling recommended.SEE TECHNICAL BULLETIN
Deprotection: SEE TECHNICAL BULLETIN (http://www.glenresearch.com/Technical/TB_2-Amino-dA.pdf) Technical Bulletin
Storage: Refrigerated storage, maximum of 2-8°C, dry
Stability in Solution: 2-3 days
The convertable nucleoside 10-1071 S6-DNP-dG-CE Phosphoramidite can also be used to incorporate 2-Amino-dA by post synthesis modification of the base after oligonucleotide synthesis.

2-Amino-dA-CED Phosphoramidite has proven to be a more reliable reagent for incorporation of 2-Amino-dA into an oligonucleotide.

Deprotection:
Acetyl-protected dC must be used during synthesis if the AMA deprotection is to be used or transamination will occur. If benzoyl-dC is used during synthesis ammonium Hydroxide for 7 days at 55oC may be used for deprotection.
  Material Safety Data Sheet

EXTINCTION DATA

Item Nucleoside λMax-1 Emax-1 λMax-2 Emax-2 E260
    (nm) (ml/µmole) nm (ml/µmole) (ml/µmole)
10-1085 2,6-diaminoPurine 278 10.2 255 9.3 8.5

Literature Highlights

Glen Report 11.1: USING MODIFIED BASES TO OPTIMIZE HYBRIDIZATION

DILUTION/COUPLING DATA

The table below shows pack size data and, for solutions, dilutions and approximate couplings based on normal priming procedures. Please link for more detailed usage information with the various synthesizers.

ABI 392/394
Cat.No. Pack
Size
Grams/
Pack
0.1M Dil.
(mL)
LV40 LV200 40nm 0.2µm 1µm 10µm
Approximate Number of Additions
10-1085-02 0.25grams .25grams 2.39 66.33 39.8 24.88 18.09 13.27 3.32
10-1085-90 100µmoles .105grams 1 20 12 7.5 5.45 4 1
10-1085-95 50µmoles .052grams .5 3.33 2 1.25 .91 .67 .17
Expedite
Cat.No. Pack
Size
Grams/
Pack
Dilution
(mL)
Molarity 50nm 0.2µm 1µm 15µm
Approximate Number of Additions
10-1085-02 0.25grams .25grams 3.56 .067 64.8 40.5 29.45 4.05
10-1085-90 100µmoles .105grams 1.5 .067 23.6 14.75 10.73 1.48
10-1085-95 50µmoles .052grams .75 .067 8.6 5.38 3.91 .54
Beckman
Cat.No. Pack
Size
Grams/
Pack
Dilution
(mL)
Molarity 30nm 200nm 1000nm
Approximate Number of Additions
10-1085-02 0.25grams .25grams 3.56 .067 66.4 41.5 30.18
10-1085-90 100µmoles .105grams 1.5 .067 25.2 15.75 11.45
10-1085-95 50µmoles .052grams .75 .067 10.2 6.38 4.64

If you cannot find the answer to your problem then please contact us or telephone +44 (0)1954 210 200

Applications & Benefits

EXTINCTION DATA

Item Nucleoside λMax-1 Emax-1 λMax-2 Emax-2 E260
    (nm) (ml/µmole) nm (ml/µmole) (ml/µmole)
10-1085 2,6-diaminoPurine 278 10.2 255 9.3 8.5



DILUTION/COUPLING DATA

The table below shows pack size data and, for solutions, dilutions and approximate couplings based on normal priming procedures.

ABI 392/394
Cat.No. Pack
Size
Grams/
Pack
0.1M Dil.
(mL)
LV40 LV200 40nm 0.2µm 1µm 10µm
Approximate Number of Additions
10-1085-02 0.25grams .25grams 2.39 66.33 39.8 24.88 18.09 13.27 3.32
10-1085-90 100µmoles .105grams 1 20 12 7.5 5.45 4 1
10-1085-95 50µmoles .052grams .5 3.33 2 1.25 .91 .67 .17
Expedite
Cat.No. Pack
Size
Grams/
Pack
Dilution
(mL)
Molarity 50nm 0.2µm 1µm 15µm
Approximate Number of Additions
10-1085-02 0.25grams .25grams 3.56 .07 64.8 40.5 29.45 4.05
10-1085-90 100µmoles .105grams 1.5 .07 23.6 14.75 10.73 1.48
10-1085-95 50µmoles .052grams .75 .07 8.6 5.38 3.91 .54
Beckman
Cat.No. Pack
Size
Grams/
Pack
Dilution
(mL)
Molarity 30nm 200nm 1000nm
Approximate Number of Additions
10-1085-02 0.25grams .25grams 3.56 .07 66.4 41.5 30.18
10-1085-90 100µmoles .105grams 1.5 .07 25.2 15.75 11.45
10-1085-95 50µmoles .052grams .75 .07 10.2 6.38 4.64
